Major Repair Kit with XL VanesMajor Repair Kit with XL Vanes - Alcatel/Adixen 2015, 65882XL
Used on:
Alcatel-Adixen 2015
Precision Scientific DD-300
For exact kit contents see bill of materials below
General product classifications
Brand | Alcatel-Adixen,Precision Scientific |
Family | Pascal DD Series |
Pump models | 2015 DD-300 |
Category | Repair Kits |
Subcategory | Major Kit |
Country of origin | US |
Manual page | ALCATEL-11 |
Part number alternatives | 23A-2015-V |
Part Number | Description | Quantity |
---|---|---|
73301 | Flat Washer, M6 | 4 |
71067 | Shaft Key | 1 |
71040 | Centering Pin | 11 |
65861 | Blade | 1 |
65857 | Membrane | 1 |
65799 | Spring | 1 |
65798 | Anti-Suckback Device, Viton | 1 |
65617 | Spring | 1 |
53474 | Oil Jet | 1 |
52655 | Discharge Valve | 4 |
52553 | Elastic Coupler | 1 |
52541 | Valve Spring | 4 |
320067 | O-Ring,Viton,63.09 X 3.53 MM | 1 |
320036 | O-Ring,Viton,12.1 X 2.7 MM | 1 |
73304 | Flat Washer, M5 | 2 |
250010 | Shouldering Ring, Coated | 1 |
65758XL | Vane, 1st Stage - X-Lon | 2 |
65756XL | Vane, 2nd Stage - X-Lon | 2 |
53040 | Vane Spring | 8 |
84646 | Waved Washer | 1 |
84149 | O-Ring,Viton,8 X 2 MM | 3 |
82604 | Plastic Drain Plug | 3 |
82063 | Shaft Seal, Viton | 4 |
65797 | Spring | 1 |
65795 | Case Gasket | 1 |
65794 | Felt Pad | 1 |
65792 | Sleeve | 1 |
65791 | Valve | 1 |
65784 | Sight Glass | 1 |
73452 | Wave Washer, M4 | 4 |
73453 | Wave Washer, M5 | 1 |
73454 | Wave Washer, M6 | 18 |
79148 | O-Ring,Viton,165 X 3 MM | 1 |
79509 | O-Ring,Viton,28 X 3 MM | 1 |
79513 | O-Ring,Viton,90 X 2 MM | 4 |
79516 | O-Ring,Viton,66 X 2.5 MM | 1 |
79537 | O-Ring,Viton,7.5 X 1.5 MM | 1 |
82004 | O-Ring,Viton,5.7 X 1.9 MM | 2 |
82014 | O-Ring,Viton,34.1 X 3.6 MM | 1 |
82025 | O-Ring,Viton,29.3 X 3.6 MM | 4 |
